C5H ChamferMate® Pipe Beveling and Deburring Machine

The Model C5H ChamferMate® pipe beveling machine is a heavy duty hydraulic machine with up to 5" inch OD capacity. With far more power than our pneumatic machines, it can machine j-bevels and other forms of custom bevels on the ends of heavy wall pipe and tubing, as well as chamfer larger sizes of solid bar or studs. The C5H can also be used as a heavy duty deburring machine.

Spare Parts List

Model C5H ChamferMate® Standard Features

• Adjustable pipe beveling from 1/2" up to 4-1/2" pipe
• Accurately machines weld bevel and faces pipe square
• Fast cycle times, normally under 20 seconds
• Adjustable cutter head with interchangeable carbide inserts set with digital calipers
• Interchangeable grips for different size pipe, tubing, and solid bar
• Electronic variable speed drive
• Heavy duty construction utilizing machine tool-type linear rails
• Hydraulic powered clamping and feed
• Coolant system
• Large chip drawer
• Can be operated by limited skilled employees

Pipe & Tube Beveling Benefits

Benefits of our chamfering machines and pipe beveling machines include:

• No more hand-grinding or torching of weld bevels
• Automated pipe beveling machines are many times faster than portable units
• Cycle normally in the 5-20 second range
• Safer than hand grinding
• Accurately machines weld bevel and faces pipe square
• Sturdy construction and quality materials for years of dependable service
• Pipe beveling machines have low operating costs
