--- title: Pipe Beveling | Chamfering Machine | Chamfering Machines description: This pipe beveling machine, the ChamferMate Model C3A, is a compact chamfering and deburring machine as well. --- [![MSI - Manufacturing Solutions, Inc.](http://www.msi-tx.com/hubfs/MSI-logo_12-2014-PMS-555.png "MSI - Manufacturing Solutions, Inc.")](http://www.msi-tx.com) # C3A-M ChamferMate® Chamfering and Parts Marking Combination Machine ![14_clipped_rev_1-1](https://www.msi-tx.com/hubfs/14_clipped_rev_1-1.png) The Model ***C3A-M ChamferMate®*** ***Combination Chamfering and Parts Marking Machine*** is a compact chamfering and stamping combination unit that features a rigid one-piece ductile iron vise, linear ball rails, heavy-duty three-bearing spindle, through-the-spindle stop rod with marking insert capabilities, and an electronic variable-speed drive to provide years of dependable service. With the addition of the marking stop rod, customers can use the C3A-M as either a chamfering machine, parts marking machine, or a combination of both functions. With use of the selector switch, users can chamfer and/or stamp ends of studs and bolts with ease. The new C3A-M will offer a diameter range of 3/8”-3” and have cycle times as low as 3 seconds per side. Adjustments are all mechanical, so no need to rely on expensive electronics like that of the competition. The C3A-M is equipped with a pneumatic cylinder that packs 16,000 pounds of force, leaving a clear, deep, easily legible stamp on the ends of bolts and studs that far exceeds that of the competition. ### Model C3A-M ChamferMate® Combo Unit Standard Features: - 3/8" to 3" OD Diameter Capacity - Chamfer and stamp in one easy process - 500 to 2000 rpm electronic variable speed drive - Adjustable cutter head for OD chamfering - Ability to chamfer (only), stamp (only), or both functions in the same cycle - Totally enclosed cutting area with chip drawer - Fully adjustable feed rate - Through-the-spindle stop rod with marking insert holder - 3-HP / 3 phase motor - Forklift slots - Collet and tool rack on side - Compact 24" x 36" floor space [Fact Sheet](https://l.msi-tx.com/hs-fs/file-15102522-pdf/docs/c3a_chamfermate.pdf?hsLang=en) [Maintenance Guide](https://l.msi-tx.com/chamfering-and-beveling/c3a-maintenance-guide?hsLang=en) [Spare Parts List ](https://l.msi-tx.com/spare-parts?hsLang=en) [Fastener Fabrication Spec Sheet](http://www.msi-tx.com/hubfs/docs/Fastener_Specifications.pdf) ### Chamfering and Beveling Benefits - No more hand grinding or beveling in a lathe - Many times faster than had methods - Chamfer and stamp in one easy process - Cycle times normally in the 2 to 5 second range - Totally enclosed cutting area for safety - Accurate repeatable chamfers - Sturdy construction and quality materials for years of dependable service - Low operation cost - [Photos](https://l.msi-tx.com/chamfering-machines/c3a-chamfermate-0#) - [Video](https://l.msi-tx.com/chamfering-machines/c3a-chamfermate-0#) - [Specs](https://l.msi-tx.com/chamfering-machines/c3a-chamfermate-0#) ![14_clipped_rev_1](https://www.msi-tx.com/hubfs/14_clipped_rev_1.png) ![blob](https://www.msi-tx.com/hubfs/blob.png)![Bolt 2](https://www.msi-tx.com/hubfs/Bolt%202.jpg)       | **SPEC** | **C3A** | | --- | --- | | Diameter Range | 3/8" to 3" OD | | Pipe Size Range | 1/2" to 2-1/2" | | Center Height | 39-1/2" | | "Typical Wall Thickness  *Varies with diameter, material, and profile. Consult Factory for your specific application.* | N/A | | Horsepower (Std) | 3 HP | | Voltage/Amp (1) | 220-3-60 / 20A | |   | 440-3-60 / 10A | | Standard RPM Range *Consult Factory for your specific RPM application.* | 500-2000 | | Pneumatic Requirement | 4 CFM @ 90 PSI | | Clamping | Pneumatic | | Spindle Feed | Air over Oil | | Feed Rate | Adjustable | | Spindle Stroke | 3" | | Coolant | Optional | | Pipe Stop (Sliding Stop) | N/A | | Type of Head (Std) | Single Tool OD Only | | Optional Head (2) | N/A | | Physical Size | 27"W x 35"D x 45"H  | | Appx Weight Lbs | 1,000 lbs | |   | | | **NOTES** | | | (1) Other voltages and frequencies available for additional cost. | | | (2) Custom heads and tool holders for special angles, J-Bevels, OD Hollow Milling, ID boring, Center Drilling, etc., are available. | | |   | | | NOTE: SPECIFICATIONS SUBJECT TO CHANGE. | | |   | | | All of MSI's chamfering machines and beveling machines can be customized to meet your individual production needs. | | [Specifications](https://l.msi-tx.com/hs-fs/file-15103127-pdf/docs/ChamferMate_Specifications.pdf?hsLang=en) [![Request a Beveled Pipe Sample](https://hubspot-no-cache-na2-prod.s3.amazonaws.com/cta/default/63827/d7992b76-6d05-482f-9eea-a88603735e62.png)](https://hubspot-cta-redirect-na2-prod.s3.amazonaws.com/cta/redirect/63827/d7992b76-6d05-482f-9eea-a88603735e62) [![Guide to Pipe Beveling](https://hubspot-no-cache-na2-prod.s3.amazonaws.com/cta/default/63827/e71e9f55-8d7b-40d2-9611-41f06390a7e3.png)](https://hubspot-cta-redirect-na2-prod.s3.amazonaws.com/cta/redirect/63827/e71e9f55-8d7b-40d2-9611-41f06390a7e3) ### Request a Quote ![sam-verified-vendor-seal](https://www.msi-tx.com/hubfs/sam-verified-vendor-seal.png "sam-verified-vendor-seal") ![Made_in_USA Seal](http://www.msi-tx.com/hs-fs/hub/63827/file-2524794046-png/images/bz-site-15/Made-in-USA.png "Made_in_USA Seal") ![Better Business Bureau Accredited Business](http://www.msi-tx.com/hs-fs/hub/63827/file-2525629113-png/images/bz-site-15/bbb.png "Better Business Bureau Accredited Business") © 2026 Manufacturing Solutions Industries, Inc. | 9485 College St., Beaumont, TX 77707
